Parameters

 Unit

 Values

 Center Wavelength

 1310, 1480,1550,1580

 Grade

 P

 Typ.peak isolation

 dB

 58

 Min.isolation @ all SOP, center wavelength +-15nm, 23°C

 dB

 46

 Max.insertion loss @ all SOP, center wavelength +-20nm, operating temp.

 dB

 0.6

 Typ.insertion loss @ all SOP, center wavelength +-20nm, 23°C

 dB

 0.4

 Typ.WDL@all SOP,operating wavelength, 23°C

 dB

 0.1

 Typ.TDL@all SOP,center wavelength, operating temp

 dB

 0.15

 Max.PDL

 dB

 0.05

 Max.PMD

 ps

 0.05

 Min.return loss

 dB

 50

 Max.optical power

 mW

 300

 Operating temperature

 °C

 -5 ~ +75

 Storage temperature

 °C

 -40 ~ +85
